INVT Goodrive300-01A Series Operation Manual page 74

Goodrive300-01A series VFD for air compressor
Function
Name
code
No-load running
P18.12
frequency
P18.13 No-load delay
P18.14 Stopping delay
P18.15 Loading delay
P18.16 Restart delay
P18.17 Pre-alarm pressure
P18.18 Alarm pressure
P18.19 Pre-alarm temperature When machine head temperature is higher
P18.20 Alarm temperature
Low-temperature
P18.21
protection threshold
Description
P01.15–P18.11 (lower-limit
load-carrying running)
The output working frequency allowed during
no-load of air compressor.
When sleep function is valid, after unloading,
the VFD runs at no-load frequency in the time
set by P18.13, and then enters sleep state.
When air consumption quantity is small, users
can enable sleep function; if sleep function is
valid, it is necessary to lower down P18.13 to
make the device enter sleep state quicker.
Setting range: 0–3600s
After the stopping command becomes valid,
the VFD will first run at no-load frequency in
the time set by P18.14, and then stops.
Setting range: 0–3600s
Loading operation is available only after the
motor runs at no-load frequency in the time
set by P18.15.
Setting range: 0–3600s
After the system stops, it is necessary to wait
until the time set by P18.16 elapsed before
restart.
Setting range: 0–3600s
When current discharge pressure is higher
than P18.17, the system indicates pressure
pre-alarm by setting BIT8 of P19.13 to 1.
When current discharge pressure is higher
than P18.18, the system indicates pressure
alarm by setting BIT10 of P19.13 to 1, and
emergency-stop will be applied.
Setting range: 0.00–P18.04
than P18.19, the
temperature pre-alarm by setting BIT9 of
P19.13 to 1.
When the machine head temperature is
higher than P18.20, the system indicates
temperature alarm by setting BIT11 of P19.13
-69-
Function code description
frequency of
system indicates
Default Modify
○
38.00 Hz
○
300s
○
0s
○
10s
○
30s
○
0.90Mpa
○
1.00Mpa
○
105° C
○
110° C
○
-10° C
