5.1 Function codes
"○" indicates the parameter value can be modified during stop and running;
"◎" indicates the parameter value cannot be modified when the VFD is running;
"●" indicates the parameter value is the actually detected value which cannot be modified.
(The modification attribute of each parameter has been restricted automatically by the VFD to avoid
inadvertent modification)
P00 group Basic functions
Function
Name
code
P00.00 Speed control mode
Running command
P00.01
channel
Communication
P00.02 running command
channel
P00.03 Max. output frequency P00.04–600.00Hz (400.00Hz)
Upper limit of running
P00.04
frequency
Lower limit of running
P00.05
frequency
A frequency command
P00.06
selection
B frequency command
P00.07
selection
Chapter 5 Function code description
0: SVC mode 0 (applicable to AM, SM)
1: SVC mode 1(applicable to AM)
2: V/F control
Note:
AM: Asynchronous motor;
SM: Synchronous motor;
If vector mode is adopted, it is a must to carry
out motor parameter autotuning on the VFD
first.
0: Keypad (LED off)
1: Terminal (LED blinks)
2: Communication (LED on)
0: Modbus communication
1–3: Reserved
P00.05–P00.03 (max. frequency)
0.00Hz–P00.04 (upper limit of running
frequency)
Note: A frequency and B frequency cannot
use the same frequency reference mode. You
can set the frequency source through P00.09.
0: Set via keypad digits
1: Set via analog P1-
2: Reserved
3: Set via analog P2-
4: Reserved
Description
-34-
Function code description
Default Modify
◎
0
○
0
○
0
◎
50.00Hz
○
50.00Hz
○
0.00Hz
○
0
○
2
