INVT Goodrive300-01A Series Operation Manual page 51

Goodrive300-01A series VFD for air compressor
Function
Name
code
Lower limit of AO1
P06.17
output
Corresponding AO1
P06.18
output of lower limit
Upper limit of AO1
P06.19
output
Corresponding AO1
P06.20
output of upper limit
P06.21 AO1 output filter time 0.000s–10.000s
Description
2: Ramps reference frequency
3: Running speed (relative to two times the
motor synchronous rotation speed)
4: Output current (relative to two times the
rated current of the VFD)
5: Output current (relative to two times the
current of the motor)
6: Output voltage (relative to 1.5 times the
rated current of the VFD)
7: Output power (relative to two times the
motor rated power)
8: Reserved
9: Output torque (relative to two times the
rated torque of the motor)
10–13: Reserved
14: Value 1
communication
15: Value 2
communication
16–21: Reserved
22: Torque current (relative to three times the
rated current of the motor)
23: Ramp frequency reference (with sign)
24: Temperature PID output
25–30: Reserved
-100.0%–P06.19
0.00V–10.00V
P06.17–100.0%
0.00V–10.00V
-46-
Function code description
set through Modbus
set through Modbus
Default Modify
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
