INVT Goodrive300-01A Series Operation Manual page 64

Goodrive300-01A series VFD for air compressor
Function
Name
code
Pre-alarm selection for
P11.08 VFD/motor
overload/underload
Fault output terminal
P11.13
action during fault
Speed deviation
P11.14
detection value
Speed deviation
P11.15
detection time
Automatic frequency
P11.16 reduction during
voltage drop
Description
0x000–0x131
LED ones:
0: Motor overload/underload
relative to the motor rated current,
1: VFD overload/underload pre-alarm, relative
to the VFD rated current
LED tens:
0: The VFD keeps running after reporting an
overload/underload alarm.
1: The VFD keeps running after reporting an
underload alarm, but it stops running after
reporting an overload alarm.
2: The VFD keeps running after reporting an
overload alarm, but it stops running after
reporting an underload alarm.
3: The VFD stops running after reporting an
overload/underload alarm.
LED hundreds:
0: Always detect
1: Detect only in constant speed running
0x00–0x11
LED ones:
0: Act during undervoltage fault
1: Do not act during undervoltage fault
LED tens:
0: Act during automatic reset period
1: Do not act during automatic reset period
0.0–50.0%
0.0–10.0s (Speed deviation protection is
disabled when P11.15 is set to 0.0)
0: Invalid
1: Valid
-59-
Function code description
Default Modify
pre-alarm,
0x000
0x00
10.0%
0.5s
1
○
○
○
○
○
