Goodrive300-01A series VFD for air compressor
2.1 Product specification
Category
Power input
Frequency
-conversion
power output
Power
–frequency fan
output (single
VFD integrated
machine)
Power output
Running
control
performance
Chapter 2 Product overview
Function
Input voltage of the VFD (V)
Rated input current (A)
Rated input frequency (Hz)
Power
Power factor
Output voltage(V)
Rated output current (A)
Rated output power (kW)
Output frequency(Hz)
Output voltage (V)
Rated output current (A)
Rated output power (kW)
Output frequency (Hz)
+24VDC power
220VAC/110VAC
Control mode
Speed regulation ratio
Speed control precision
Speed fluctuation
Torque response
Starting torque
Frequency reference mode
Overload capacity
Dedicated function
Analog pressure input
Analog temperature input
Digital input
Specification
3PH 380V (-15%)–440V (+10%)
3PH 220V (-15%)–240V (+10%)
Refer to 2.4 "Rated specifications".
50Hz or 60Hz, allowed range: 47–63Hz
> 97%
0.9
Equal to input voltage, error ratio: less than 5%
Refer to 2.4 "Rated specifications".
Refer to 2.4 "Rated specifications".
0–400Hz
Equal to input voltage, error ratio: less than 1%
Refer to 2.4 "Rated specifications".
Refer to 2.4 "Rated specifications".
Equal to input frequency, error ratio: less than
1%
24W
15W (for single VFD integrated machine)
Open loop vector, space voltage vector
Asynchronous motor: 1:200 (SVC);
Synchronous motor: 1:20 (SVC)
±0.2% (SVC)
±0.3% (SVC)
<20ms (SVC)
Asynchronous motor: 0.25Hz 150% (SVC)
Synchronous motor: 2.5Hz 150% (SVC)
PID control, Modbus communication, P1- and
P2- analog input, keypad digital input
1min at 150%
Sleep and wake-up function, constant pressure
control, constant temperature control, parts
maintenance, phase sequence detection, fan
overload protection
Two 4–20mA/0–1.6MPa inputs
Two analog temperature inputs; resolution rate:
1° C; Range: -20° C–150° C; precision error: 3° C
Five normal inputs, max frequency: 1kHz
