Goodrive300-01A series VFD for air compressor
Note:
 Fan VFD information can be information only about Goodrive300-21 series VFD.
 VFD information is read only.
B.1.7 System configuration
Enter a correct factory password to enter the system configuration interface.
B.1.7.1 Factory commissioning wizard
Factory commissioning procedure
Step 1 Enter the master parameter setting interface.
Set motor parameters according to the motor nameplate. Perform motor parameter identifying. Enter
motor parameters for motor variable-frequency commissioning. Parameter autotuning is located at
the last line in the master parameter setting interface, as shown in Figure B-50.
03.17 16:02:35
Factory debug guide
Password setting
Time setting
Backlight setting
Function code search
VFD model
Return
Param copy function
Return
Figure B-48 System configuration interface
03.17 16:02:35
Master param setting
Fan param setting
Input channel setting
System param setting
Set param with one key
Debug mode
Return
Figure B-49 Factory commissioning wizard interface
Systerm config
Home
Home
Factory debug guide
Home
