Goodrive300-01A series VFD for air compressor
B.1.3.2 Cable description
Note: The emergency stop cable is used for emergency stop control when a device fault occurs and it
is often connected to the S1 terminal and COM terminal.
+24V
485+
485-
GND
70± 10 (mm)
Network port diagram
OG&WH
OG
GN&WH
BU
BU&WH
GN
BN&WH
BN
B.1.4 Setting parameters on the LCD keypad
B.1.4.1 Initial interface
After power-on and startup, the initial interface appears, as shown in Figure B-7. The LCD keypad
displays the product name and software version on this interface and goes to the working
environment interface three seconds later.
Figure B-5 Emergency stop cable diagram
Figure B-6 RS485 communication cable diagram
Table B-3 Wires and terminals
Terminal
GND
1
485-
2
3
4
5
6
7
485+
8
+24V
Emergency stop signal
Emergency stop signal
2500± 5(mm)
Orange&white
Orange
Green&white
Blue
Blue&white
Green
Brown&white
Brown
