INVT Goodrive300-01A Series Operation Manual page 46

Goodrive300-01A series VFD for air compressor
Function
Name
code
of motor 1
V/F voltage point 3 of
P04.08
motor 1
V/F slip compensation
P04.09
gain of motor 1
Low-frequency
P04.10 vibration control factor
of motor 1
High-frequency
P04.11 vibration control factor
of motor 1
Vibration control
P04.12
threshold of motor 1
Energy conservation
P04.26
running selection
Flux-weakening
P04.33 coefficient in constant
power area
Reactive closed-loop
P04.34
proportional coefficient
Reactive closed-loop
P04.35
integral coefficient
P05 group Input terminals
Function
Name
code
P05.00 Reserved
S1 terminal function
P05.01
selection
S2 terminal function
P05.02
selection
S3 terminal function
P05.03
selection
Description
/P04.05–P02.16 (rated frequency of motor 1)
0.0%–110.0% (rated voltage of motor 1)
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (max. frequency)
0: No action
1: Automatic energy-saving running
1.00–1.30
0–3000
When the SM V/F control mode is enabled,
the function code is used to set the
proportional coefficient of the reactive current
closed-loop control.
0–3000
When the SM V/F control mode is enabled,
the function code is used to set the integral
coefficient of the reactive current closed-loop
control.
Description
Reserved
0: No function
1: Forward running
2: Reverse running
3: Three-line running control
4: Forward jogging
5: Reverse jogging
-41-
Function code description
Default Modify
○
00.0%
○
100.0%
○
10
○
10
○
30.00Hz
◎
0
○
1.00
○
100
○
20
Default Modify
◎
0
◎
0
◎
0
◎
0
