Goodrive300-01A series VFD for air compressor
Function
Name
code
Integral time of digital
P08.43
potentiometer
UP/DOWN terminal
P08.44
control setup
UP terminal frequency
P08.45 incremental change
DOWN terminal
P08.46 frequency decremental
change rate
Action selection for
P08.47 frequency setup during
power down
potentiometer integral function
0: The integral function is valid
1: The integral function is invalid
0.01–10.00s
0x00–0x221
LED ones: Frequency enabling selection
0: UP/DOWN terminal setup is valid
1: UP/DOWN terminal setup is invalid
LED tens: Frequency control selection
0: Valid only when P00.06 =0
1: All frequency modes are valid
2: Invalid for multi-step speed when multi-step
speed takes priority
LED hundreds: Action selection during stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
0.01–50.00Hz/s
rate
0.01–50.00Hz/s
0x000–0x111
LED ones: Action selection at power-off
during frequency adjusting through digitals.
0: Save the setting at power-off.
1: Clear the setting at power-off.
LED tens: Action selection at power-off during
frequency
communication
0: Save the setting at power-off.
1: Clear the setting at power-off.
LED hundreds: Action selection at power-off
during frequency adjusting through other
communication
0: Save the setting at power-off.
Description
adjusting through
-54-
Function code description
Default Modify
0.10s
0x000
0.50Hz/s
0.50Hz/s
Modbus
0x000
○
○
○
○
○
