INVT Goodrive300-01A Series Operation Manual page 66

Goodrive300-01A series VFD for air compressor
Function
Name
code
P14.02 Data bit check setup
Communication
P14.03
response delay
Communication
P14.04
timeout fault time
Transmission error
P14.05
processing
Communication
P14.06 processing action
selection
P15 group Non-standard functions
Function
code
Auxiliary pressure
P15.00 start protection
0: No parity check (N, 8, 1) for RTU
1: Even parity (E, 8, 1) for RTU
2: Odd parity (O, 8, 1) for RTU
3: No parity check (N, 8, 2) for RTU
4: Even parity (E, 8, 2) for RTU
5: Odd parity (O, 8, 2) for RTU
0–200ms
0.0 (invalid), 0.1–60.0s
0–4
0: Alarm and coast to stop
1: Do not alarm and continue running
2: Do not alarm and stop as per stop mode
(under communication control mode only)
3: Do not alarm and stop as per stop mode
(under all control modes)
4: Alarm and coast to stop, and automatic
fault reset after communication is restored
0x000–0x111
LED ones: write operation action
0: There is response for write operation
1: There is no response for write operation
LED tens: Communication encryption
processing
0: Communication encryption setting is invalid
1: Communication encryption setting is valid
LED hundreds: Communication CRC check
failure handling
0: Return error type 06
1: Do not return any data (This function is
used with the Plot controller)
Name
0: Disable
1: Enable
enable
Description
Description
-61-
Function code description
Default Modify
○
1
○
5ms
○
0.0s
○
0
○
0x00
Default Modify
◎
0
