Goodrive300-01A series VFD for air compressor
P03 group Vector control
Function
Name
code
ASR proportional gain
P03.00
P03.01 ASR integral time 1
Switching low point
P03.02
frequency
ASR proportional gain
P03.03
P03.04 ASR integral time 2
Switching high point
P03.05
frequency
P03.06 ASR output filter
Vector control
electromotion slip
P03.07
compensation
coefficient
Vector control power
generation slip
P03.08
compensation
coefficient
ACR proportional
P03.09
coefficient P
ACR integral
P03.10
coefficient I
Keypad setting of the
P03.20 upper limit of
electromotive torque
0–200.0
1
0.000–10.000s
0.00Hz–P03.05
0–200.0
2
0.000–10.000s
P03.02–P00.03 (max. output frequency)
0–8 (corresponds to 0–2^8/10ms)
50%–200%
50%–200%
0–65535
The default value of P03.09 and P03.10 is
different within differing power ranges, and
the default value will be configured as below
after autotuning and setting power range via
the touch screen.
P03.09 value
(reference)
2000
2500
3000
3500
4000
0.0–300.0% (rated motor current)
Description
P03.10 value
Motor power
(reference)
1000 7.5–22kW
1500 30–37kW
1500 45–90kW
2000 110–132kW
2000 160–315kW
-39-
Function code description
Default Modify
○
20.0
○
0.200s
○
5.00Hz
○
20.0
○
0.200s
○
10.00Hz
○
0
○
100%
○
100%
Depend
○
on
model
Depend
○
on
model
○
180.0%
