Goodrive300-01A series VFD for air compressor
Function
Name
code
Power calibration
P18.22
coefficient
Temperature PID
P18.23
calculation cycle (Ts)
P18.24 Gain coefficient (kp)
Convergence
P18.25
coefficient (K)
Upper limit of
P18.26
temperature PID
Lower limit of
P18.27
temperature PID
Lower limit voltage of
P18.28
PT1 (-20° C)
Upper limit voltage of
P18.29
PT1 (120° C)
Description
to 1, and emergency-stop will be applied.
When machine head temperature is lower
than P18.21, the
low-temperature pre-alarm by setting BIT14 of
P19.13 to 1, and air compressor cannot start.
Setting range: -20–150
It is used to calibrate the displayed value of
P19.10 [actual motor output power].
Setting range: 0%–200%
Set the sampling cycle of temperature PID.
Setting range: 0.0–10.0s
It determines the regulation intensity of
temperature PID regulator, the larger the
value of kp, the stronger the regulation
intensity, however,
temperature oscillation may occur, users can
fine-tune based on the default value.
Setting range: 0.0–100.0
It determines the converging speed of
temperature PID regulator, the larger the
value of K, the stronger the converging
intensity, however,
temperature oscillation may occur, users can
fine-tune based on the default value.
Setting range: 0.00–1.00
It is used to limit the output value of
temperature PID, of which 100% corresponds
to the P00.03 max. output frequency of fan.
Setting range: 0.00–100.00%
It is used to calibrate temperature detection
circuit before shipment.
Connect to the resistor whose resistance is
the same with that of PT100 at -20° C, read
the voltage value of P17.20 and input it to
P18.28.
Connect to the resistor whose resistance is
the same with that of PT100 at 120° C, read
the voltage value of P17.20 and input it to
-70-
Function code description
system indicates
if it is too large,
if it is too large,
Default Modify
○
100%
○
2.0s
○
18.0
○
0.12
○
100.00%
○
10.00%
○
3.10V
○
8.10V
