Goodrive300-01A series VFD for air compressor
103
Keypad installation bracket
B.1.3 RS485 communication cable
B.1.3.1 Connection description
Please use the provided RS485 communication cable, of which one end is connected to the keypad
network port and the other is connected to the CN7 terminal of the VFD control board.
Emergency stop signal
Output voltage 220AC
4-R12
Figure B-3 Keypad installation bracket
wiring
Multifunctional terminals
GD300-01A control
Figure B-4 RS485 communication cable connection diagram
98
Installation dimensions
Pressure sensor interface 24V 4-20mA
PT100 temperature sensor interface
board
-110-
External optional accessories
RS485 keypad
Network
+24V
GND
485+
port
485-
RS485
communication
cable
CN7
