INVT Goodrive300-01A Series Operation Manual page 13

Goodrive300-01A series VFD for air compressor
Sign Description
○
3
Voltage class
Power-frequency fan/
○
4
Built-in transformer
2.4 Rated specifications
2.4.1 Rated specifications of single-VFD products
AC 3PH 220V(-15%)–240V(+10%)
Product model
GD300-01A-7R5G-2
GD300-01A-011G-2
GD300-01A-015G-2
GD300-01A-018G-2
GD300-01A-022G-2
GD300-01A-030G-2
GD300-01A-037G-2
GD300-01A-045G-2
GD300-01A-055G-2
GD300-01A-075G-2
GD300-01A-090G-2
GD300-01A-110G-2
2: AC 3PH 220V(-15%)–240V(+10%)
4: AC 3PH 380V(-15%)–440V(+10%)
Empty: VFD dedicated for single-VFD air compressor
Single-VFD air compressor integrated machine
C: Built-in contactor unit, supporting power-frequency fan
output
T: Built-in
220V/110V power supply
Output power Input current
(kW)
7.5
11
15
18.5
22
30
37
45
55
75
90
110
Content
power-frequency
Output current
(A) (A)
32 30
44 42
58 55
72 70
87 80
106 110
140 130
170 160
202 200
310 270
345 320
385 380
-8-
Product overview
transformer, providing
Installation dimension
description
Same as GD300-
01A-015G-4
Same as
GD300-01A-022G-4
Same as
GD300-01A-030G-4
Same as
GD300-01A-037G-4
Same as
GD300-01A-045G-4
Same as
GD300-01A-055G-4
Same as
GD300-01A-075G-4
Same as
GD300-01A-090G-4
Same as
GD300-01A-110G-4
Same as
GD300-01A-160G-4
Same as
GD300-01A-185G-4
Same as
GD300-01A-200G-4
