Goodrive300-01A series VFD for air compressor
P19.13 State type
Temperature signal
BIT13=1
Low-temperature
BIT14=1
protection pre-alarm
P19.14 State type
Part 1 needs
BIT0=1
maintenance
Part 2 needs
BIT1=1
maintenance
Part 3 needs
BIT2=1
maintenance
Part 4 needs
BIT3=1
maintenance
Part 5 needs
BIT4=1
maintenance
Auxiliary pressure
BIT5=1
signal fault
Auxiliary temperature
BIT6=1
signal fault
Possible cause

PT100 sensor is
fault disconnected.

The actual temperature
detected by PT1 is less
than the low
temperature protection
threshold set by
P18.21.
Possible cause

The running time of part
1 exceeds the time set
by P19.00.

The running time of part
2 exceeds the time set
by P19.01.

The running time of part
3 exceeds the time set
by P19.02.

The running time of part
4 exceeds the time set
by P19.03.

The running time of part
5 exceeds the time set
by P19.04.

The actual voltage
detected by P2 is less
than 1V.

PT100 sensor is
disconnected.
Fault information and troubleshooting
not select current signal.

Check whether the wiring of
PT100 is normal.

Check whether temperature
detection sensor is abnormal.

Temperature detection input
circuit is abnormal.

Temperature detection sensor
is abnormal.

Temperature detection input
circuit is abnormal.

Actual temperature is too low,
and low temperature
pre-alarm is reported
accordingly, and therefore the
air compressor cannot start.








-96-
Solution
Solution
Carry out maintenance after
stop
Carry out maintenance after
stop
Carry out maintenance after
stop
Carry out maintenance after
stop
Carry out maintenance after
stop
Pressure detection sensor is
abnormal.
Pressure detection input P2
signal wire is disconnected.
Check whether the wiring of
PT100 is normal.
