Goodrive300-01A series VFD for air compressor
P06 group Output terminals
Function
Name
code
P06.01 Reserved
P06.02 RO3 output selection
P06.03 RO1 output selection
P06.04 RO2 output selection
Output terminal
P06.05
polarity selection
P06.08 RO3 switch-on delay 0.000–50.000s
P06.09 RO3 switch-off delay 0.000–50.000s
P06.10 RO1 switch-on delay 0.000–50.000s
P06.11 RO1 switch-off delay 0.000–50.000s
P06.12 RO2 switch-on delay 0.000–50.000s
P06.13 RO2 switch-off delay 0.000–50.000s
P06.14 AO1 output selection
Description
0: Invalid
1: In running
2: In forward running
3: In reverse running
4: In jogging
5: VFD fault
6–11: Reserved
12: Ready to run
13: In pre-exciting
14–19: Reserved
20: External fault is valid
21–22: Reserved
23: Modbus communication virtual terminal
output
24–25: Reserved
26: Function only for oil pump (blower)
27: Fan start/stop control
28: Solenoid valve control output
29: Cooling fan control of main motor
30: Reserved
This function code is used to set the output
terminal polarity.
When the bit is set to 0, output terminal
polarity is positive;
When the bit is set to 1, output terminal
polarity is negative.
BIT3 BIT2
RO2 RO1
Setting range: 0–0xF
0: Running frequency
1: Set frequency
-45-
Function code description
BIT1 BIT0
RO3 Reserved
Default Modify
○
0
○
0
○
0
○
0
○
0
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
24
