INVT Goodrive300-01A Series Operation Manual page 107

Goodrive300-01A series VFD for air compressor
W1
H1
Table A-1 Wall installation dimension of 7.5kW–315kW single VFD (unit: mm)
Power
7.5kW
11kW–22kW
30kW–37kW
45kW–55kW
75kW
90kW–110kW
132kW–200kW
220kW–315kW
Figure A-6 220kW–315kW wall installation diagram
W1 W2 W3
170 151 /
200 185 /
250 230 /
282 160 226.0
370 220 /
338 200 /
500 180 /
680 230 /
Figure A-7 220kW–315kW floor installation diagram
D1
H2
H1 H2 D1
320 303.5 196.5
340.5 328.5 184.5
400 380 202
560 542 238
590 572 250
554 535 337
870 850 360
960 926 380
-102-
Product dimension
W2 W2
Diameter of
D2
mounting hole
113 Ø 6
104.5 Ø 6
123.5 Ø 6
138 Ø 9
/ Ø 9
/ Ø 9.5
/ Ø 11
/ Ø 13
