INVT Goodrive300-01A Series Operation Manual page 166

Goodrive300-01A series VFD for air compressor
Function
description
Address
definition
Upper limit torque of brake torque (0–3000,
2008H 1000 corresponds to 100.0% rated motor
current)
Special control command word:
Bit0–1: =00: Motor 1
Bit2: =1 Torque control =0: Speed control
2009H Bit3: =1 Power consumption cleared to zero
=0: Power consumption not cleared to zero
Bit4: =1 Pre-excitation =0: Pre-excitation
forbidden
Bit5: =1 DC brake =0: DC brake forbidden
Virtual
200AH
0x000–0x1FF
Virtual output terminal command, range:
200BH
0x00–0x0F
The set
separation)
200CH
(0–1000, 1000 corresponds to 100.0% rated
motor voltage)
The set value 1 of AO output (-1000–1000,
200DH
1000 corresponds to 100.0%)
The set value 2 of AO output (-1000–1000,
200EH
1000 corresponds to 100.0%)
BIT0: =1 running time of part 1 cleared to
zero; =0: invalid
BIT1: =1 running time of part 2 cleared to zero
=0: invalid
BIT2: =1 running time of part 3 cleared to zero
=0: invalid
BIT3: =1 running time of part 4 cleared to zero
200FH
=0: invalid
BIT4: =1 running time of part 5 cleared to zero
=0: invalid
BIT5: =1 device running time cleared to zero
=0: invalid
BIT6: =1 solenoid valve loading =0: solenoid
valve unloading
Data meaning
=01: Motor 2
=10: Motor 3 =11: Motor 4
input terminal command,
voltage value
-161-
Communication protocol
range:
(used for V/F
R/W
attribute
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
