INVT Goodrive300-01A Series Operation Manual page 42

Goodrive300-01A series VFD for air compressor
Function
Name
code
P02.03 Rated speed of AM 1 1–36000rpm
P02.04 Rated voltage of AM 1 0–1200V
P02.05 Rated current of AM 1 0.8–6000.0A
P02.06 Stator resistor of AM 1 0.001–65.535Ω
P02.07 Rotor resistor of AM 1 0.001–65.535Ω
Leakage inductance of
P02.08
Mutual inductance of
P02.09
No-load current of AM
P02.10
Saturation coefficient 1
P02.11
of the iron core of AM 1
Saturation coefficient 2
P02.12
of the iron core of AM 1
Saturation coefficient 3
P02.13
of the iron core of AM 1
Saturation coefficient 4
P02.14
of the iron core of AM 1
P02.15 Rated power of SM 1 0.1–3000.0kW
Rated frequency of SM
P02.16
P02.17 Pole pairs of SM 1
P02.18 Rated voltage of SM 1 0–1200V
P02.19 Rated current of SM 1 0.8–6000.0A
P02.20 Stator resistor of SM 1 0.001–65.535Ω
Direct-axis inductance
P02.21
of SM 1
0.1–6553.5mH
AM 1
0.1–6553.5mH
AM 1
0.1–6553.5A
1
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.01Hz–P00.03 (max. frequency)
1
1–50
0.01–655.35mH
Description
-37-
Function code description
Default Modify
Depend
◎
on model
Depend
◎
on model
Depend
◎
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
◎
80.0%
◎
68.0%
◎
57.0%
◎
40.0%
Depend
◎
on model
◎
50.00Hz
◎
2
Depend
◎
on model
Depend
◎
on model
Depend
○
on model
Depend
○
on model
