Goodrive300-01A series VFD for air compressor
Protection
parameter
Prealarm
pressure
Alarm pressure
Auxiliary
temperature
prealarm
Auxiliary
temperature
alarm
Auxiliary pressure
prealarm
Alarm auxiliary
pressure
Low temperature
protection
threshold
Current auxiliary
temperature
Current auxiliary
pressure
Enable auxiliary
temperature
protection
Enable auxiliary
pressure
protection
2. You can edit parameters only after entering the correct administrator password.
Initial value
When the actual air supply pressure is higher than this
0.90Mpa
pressure, a pre-alarm is reported.
When the actual air supply pressure is higher than this
1.00Mpa
pressure, an alarm is reported, and the device is stopped.
When
105° C temperature, a pre-alarm is reported. This parameter is valid
only after it is enabled in system configuration.
When
temperature, an alarm is reported, and the device is stopped.
110° C
This parameter is valid only after it is enabled in system
configuration.
When the detected pressure is higher than this pressure, a
0.90Mpa pre-alarm is reported. This parameter is valid only after it is
enabled in system configuration.
When the detected pressure is higher than this pressure, an
1.00Mpa alarm is reported. This parameter is valid only after it is
enabled in system configuration.
When the detected temperature is lower than this temperature,
-10° C a low temperature pre-alarm is reported. This parameter is
valid only after it is enabled in system configuration.
/ It displays the auxiliary temperature that is currently detected.
/ It displays the auxiliary pressure that is currently detected.
Disable Disable/Enable
Disable Disable/Enable
Function
the detected temperature
the detected temperature
-124-
External optional accessories
is higher than
is higher than
