INVT Goodrive300-01A Series Operation Manual page 77

Goodrive300-01A series VFD for air compressor
Function
Name
code
Pressure sensor
P18.37
channel
Upper limit of pressure
P18.38
sensor P2
Auxiliary pressure
P18.39
protection enable
Auxiliary pressure
P18.40
pre-alarm
Auxiliary pressure
P18.41
Fan frequency
P18.42
reference mode
P18.43 Fan control mode
by setting BIT10 of P19.14 to 1, and
emergency-stop will be applied.
0: Discharge pressure P1, auxiliary pressure
P2
1: Discharge pressure P2, auxiliary pressure
P1
2: Pressure display in normal VFD mode
(P18.00=0) (main pressure P1, auxiliary
temperature P2)
0.00–20.00 Mpa
It is related to the actual range of pressure
sensor, the corresponding voltage of P18.04
is P05.44.
Note: When restoring to default values, the
value will stay in current value.
0: Invalid
1: Valid
0.00–20.00
When P18.39 is enabled and the auxiliary
pressure is larger than P18.40, the system
indicates auxiliary pressure pre-alarm by
setting BIT7 of P19.14 to 1.
0.00–20.00
When P18.39 is enabled and the auxiliary
pressure is larger than P18.41, the system
alarm indicates pressure alarm by setting BIT9 of
P19.14 to 1, and emergency stop will be
applied.
0: Temperature PID
1: Analog P2- setting
2: RS485 communication
0: Air compressor mode, the power-frequency
fan starts/stops as per the temperature;
1:
starts/stops via terminals;
2: 485 communication (address 0X201B, write
1 to start, write 3 to stop)
Description
Terminal, the power-frequency
-72-
Function code description
Default Modify
◎
0
◎
1.60Mpa
◎
0
○
0.90Mpa
○
1.00Mpa
◎
0
fan
◎
0
