set_property PACKAGE_PIN AB31 [get_ports FMC2_HPC_HA06_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA06_P]
set_property PACKAGE_PIN AB32 [get_ports FMC2_HPC_HA06_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA06_N]
set_property PACKAGE_PIN AC31 [get_ports FMC2_HPC_HA07_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA07_P]
set_property PACKAGE_PIN AD31 [get_ports FMC2_HPC_HA07_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA07_N]
set_property PACKAGE_PIN AA31 [get_ports FMC2_HPC_HA08_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA08_P]
set_property PACKAGE_PIN AA32 [get_ports FMC2_HPC_HA08_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA08_N]
set_property PACKAGE_PIN AE29 [get_ports FMC2_HPC_HA09_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA09_P]
set_property PACKAGE_PIN AE30 [get_ports FMC2_HPC_HA09_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA09_N]
set_property PACKAGE_PIN AF31 [get_ports FMC2_HPC_HA10_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA10_P]
set_property PACKAGE_PIN AF32 [get_ports FMC2_HPC_HA10_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA10_N]
set_property PACKAGE_PIN AE34 [get_ports FMC2_HPC_HA11_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA11_P]
set_property PACKAGE_PIN AE35 [get_ports FMC2_HPC_HA11_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA11_N]
set_property PACKAGE_PIN AF34 [get_ports FMC2_HPC_HA12_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA12_P]
set_property PACKAGE_PIN AG34 [get_ports FMC2_HPC_HA12_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA12_N]
set_property PACKAGE_PIN AE32 [get_ports FMC2_HPC_HA13_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA13_P]
set_property PACKAGE_PIN AE33 [get_ports FMC2_HPC_HA13_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA13_N]
set_property PACKAGE_PIN AF35 [get_ports FMC2_HPC_HA14_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA14_P]
set_property PACKAGE_PIN AF36 [get_ports FMC2_HPC_HA14_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA14_N]
set_property PACKAGE_PIN AE37 [get_ports FMC2_HPC_HA15_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA15_P]
set_property PACKAGE_PIN AF37 [get_ports FMC2_HPC_HA15_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA15_N]
set_property PACKAGE_PIN AG36 [get_ports FMC2_HPC_HA16_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA16_P]
set_property PACKAGE_PIN AH36 [get_ports FMC2_HPC_HA16_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA16_N]
set_property PACKAGE_PIN AC34 [get_ports FMC2_HPC_HA17_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA17_CC_P]
set_property PACKAGE_PIN AD35 [get_ports FMC2_HPC_HA17_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA17_CC_N]
set_property PACKAGE_PIN AB36 [get_ports FMC2_HPC_HA18_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA18_P]
set_property PACKAGE_PIN AB37 [get_ports FMC2_HPC_HA18_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA18_N]
set_property PACKAGE_PIN AC35 [get_ports FMC2_HPC_HA19_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA19_P]
set_property PACKAGE_PIN AC36 [get_ports FMC2_HPC_HA19_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA19_N]
set_property PACKAGE_PIN AD36 [get_ports FMC2_HPC_HA20_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HPC_HA20_P]
set_property PACKAGE_PIN AD37 [get_ports FMC2_HPC_HA20_N]
