Xilinx VC707 User Manual page 17

Table 1-4: DDR3 Memory Connections to the FPGA (Cont'd)
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
FPGA (U1)
Net Name
Pin
K15 DDR3_DM1
F12 DDR3_DM2
A14 DDR3_DM3
C23 DDR3_DM4
D25 DDR3_DM5
C31 DDR3_DM6
F31 DDR3_DM7
M16 DDR3_DQS0_N
N16 DDR3_DQS0_P
J12 DDR3_DQS1_N
K12 DDR3_DQS1_P
G16 DDR3_DQS2_N
H16 DDR3_DQS2_P
C14 DDR3_DQS3_N
C15 DDR3_DQS3_P
A27 DDR3_DQS4_N
A26 DDR3_DQS4_P
E25 DDR3_DQS5_N
F25 DDR3_DQS5_P
B29 DDR3_DQS6_N
B28 DDR3_DQS6_P
E28 DDR3_DQS7_N
E27 DDR3_DQS7_P
H20 DDR3_ODT0
H18 DDR3_ODT1
C29 DDR3_RESET_B
J17 DDR3_S0_B
J20 DDR3_S1_B
G17 DDR3_TEMP_EVENT
F20 DDR3_WE_B
K17 DDR3_CAS_B
E20 DDR3_RAS_B
www.xilinx.com
Feature Descriptions
J1 DDR3 Memory
Pin Number Pin Name
28 DM1
46 DM2
63 DM3
136 DM4
153 DM5
170 DM6
187 DM7
10 DQS0_N
12 DQS0_P
27 DQS1_N
29 DQS1_P
45 DQS2_N
47 DQS2_P
62 DQS3_N
64 DQS3_P
135 DQS4_N
137 DQS4_P
152 DQS5_N
154 DQS5_P
169 DQS6_N
171 DQS6_P
186 DQS7_N
188 DQS7_P
116 ODT0
120 ODT1
30 RESET_B
114 S0_B
121 S1_B
198 EVENT_B
113 WE_B
115 CAS_B
110 RAS_B
Send Feedback
17
