Xilinx VC707 User Manual page 52

Chapter 1: VC707 Evaluation Board Features
User Pushbuttons
Figure 1-25
X-Ref Target - Figure 1-25
SW7
GPIO SW W 4
3
R40
4.7kΩ
0.1 W
5%
GND
52
Send Feedback
shows the user pushbutton switch circuits.
GPIO SW N 4
3
GND
VCC1V8
1 GPIO SW C 4
2 3
GND
GPIO SW S 4
3
GND
Figure 1-25: User Pushbuttons
www.xilinx.com
VCC1V8
SW3
1
2
R36
4.7kΩ
0.1 W
5%
VADJ
SW6
1 GPIO SW E
2
R39
4.7kΩ
0.1 W
5%
VCC1V8
SW5
1
2
R38
4.7kΩ
0.1 W
5%
VCC1V8
SW4
4 1
3 2
R37
4.7kΩ
0.1 W
5%
GND
UG885_c1_24_012113
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
