Xilinx VC707 User Manual page 19

Table 1-5: BPI Flash Memory Connections to the FPGA (Cont'd)
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
FPGA (U1) Pin Net Name
AF30 FLASH_A3
AK29 FLASH_A4
AK28 FLASH_A5
AG29 FLASH_A6
AK30 FLASH_A7
AJ30 FLASH_A8
AH30 FLASH_A9
AH29 FLASH_A10
AL30 FLASH_A11
AL29 FLASH_A12
AN33 FLASH_A13
AM33 FLASH_A14
AM32 FLASH_A15
AV41 FLASH_A16
AU41 FLASH_A17
BA42 FLASH_A18
AU42 FLASH_A19
AT41 FLASH_A20
BA39 FLASH_A21
BA39 FLASH_A22
BB39 FLASH_A23
AW42 FLASH_A24
AW41 FLASH_A25
NA NC
AM36 FLASH_D0
AN36 FLASH_D1
AJ36 FLASH_D2
AJ37 FLASH_D3
AK37 FLASH_D4
AL37 FLASH_D5
AN35 FLASH_D6
AP35 FLASH_D7
www.xilinx.com
BPI Flash Memory (U3)
Pin Number Pin Name
D1 A4
D2 A5
A2 A6
C2 A7
A3 A8
B3 A9
C3 A10
D3 A11
C4 A12
A5 A13
B5 A14
C5 A15
D7 A16
D8 A17
A7 A18
B7 A19
C7 A20
C8 A21
A8 A22
G1 A23
H8 A24
B6 A25
B8 A26
H1 A27
F2 DQ0
E2 DQ1
G3 DQ2
E4 DQ3
E5 DQ4
G5 DQ5
G6 DQ6
H7 DQ7
Send Feedback
Feature Descriptions
19
