Xilinx VC707 User Manual page 60

Chapter 1: VC707 Evaluation Board Features
Table 1-27
Table 1-27: J35 VITA 57.1 FMC 1 HPC Connections
J35
FMC 1 Schematic Net Name
HPC Pin
A2 FMC1_HPC_DP1_M2C_P
A3 FMC1_HPC_DP1_M2C_N
A6 FMC1_HPC_DP2_M2C_P
A7 FMC1_HPC_DP2_M2C_N
A10 FMC1_HPC_DP3_M2C_P
A11 FMC1_HPC_DP3_M2C_N
A14 FMC1_HPC_DP4_M2C_P
A15 FMC1_HPC_DP4_M2C_N
A18 FMC1_HPC_DP5_M2C_P
A19 FMC1_HPC_DP5_M2C_N
A22 FMC1_HPC_DP1_C2M_P
A23 FMC1_HPC_DP1_C2M_N
A26 FMC1_HPC_DP2_C2M_P
A27 FMC1_HPC_DP2_C2M_N
A30 FMC1_HPC_DP3_C2M_P
A31 FMC1_HPC_DP3_C2M_N
A34 FMC1_HPC_DP4_C2M_P
A35 FMC1_HPC_DP4_C2M_N
A38 FMC1_HPC_DP5_C2M_P
A39 FMC1_HPC_DP5_C2M_N
60
Send Feedback
lists the connections between the FMC1 HPC J35 connector and the FPGA U1.
J35
U1 FPGA
FMC 1
Pin
HPC Pin
C6 B1
C5 B4
B8 B5
B7 B8
A6 B9
A5 B12
H8 B13
H7 B16
G6 B17
G5 B20
D4 B21
D3 B24
C2 B25
C1 B28
B4 B29
B3 B32
J2 B33
J1 B36
H4 B37
H3 B40
www.xilinx.com
Schematic Net Name
NC
NC
NC
NC
NC
FMC1_HPC_DP7_M2C_P
FMC1_HPC_DP7_M2C_N
FMC1_HPC_DP6_M2C_P
FMC1_HPC_DP6_M2C_N
FMC1_HPC_GBTCLK1_M2C_P
FMC1_HPC_GBTCLK1_M2C_N
NC
NC
NC
NC
FMC1_HPC_DP7_C2M_P
FMC1_HPC_DP7_C2M_N
FMC1_HPC_DP6_C2M_P
FMC1_HPC_DP6_C2M_N
NC
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
U1 FPGA
Pin
E6
E5
F8
F7
E10
E9
F4
F3
G2
G1
