Xilinx VC707 User Manual page 64

Chapter 1: VC707 Evaluation Board Features
Table 1-27: J35 VITA 57.1 FMC 1 HPC Connections (Cont'd)
J35
FMC 1 Schematic Net Name
HPC Pin
J2 NC
J3 NC
J6 FMC1_HPC_HA03_P
J7 FMC1_HPC_HA03_N
J9 FMC1_HPC_HA07_P
J10 FMC1_HPC_HA07_N
J12 FMC1_HPC_HA11_P
J13 FMC1_HPC_HA11_N
J15 FMC1_HPC_HA14_P
J16 FMC1_HPC_HA14_N
J18 FMC1_HPC_HA18_P
J19 FMC1_HPC_HA18_N
J21 FMC1_HPC_HA22_P
J22 FMC1_HPC_HA22_N
J24 FMC1_HPC_HB01_P
J25 FMC1_HPC_HB01_N
J27 FMC1_HPC_HB07_P
J28 FMC1_HPC_HB07_N
J30 FMC1_HPC_HB11_P
J31 FMC1_HPC_HB11_N
J33 FMC1_HPC_HB15_P
J34 FMC1_HPC_HB15_N
J36 FMC1_HPC_HB18_P
J37 FMC1_HPC_HB18_N
J39 FMC1_VIO_B_M2C
64
Send Feedback
J35
U1 FPGA
FMC 1
Pin
HPC Pin
K1
K4
H33 K5
G33 K7
C38 K8
C39 K10
J37 K11
J38 K13
E37 K14
E38 K16
F39 K17
E39 K19
F36 K20
F37 K22
H28 K23
H29 K25
G26 K26
G27 K28
K22 K29
J22 K31
M21 K32
L21 K34
G21 K35
G22 K37
K38
BANK 36 K40
VCCO
www.xilinx.com
Schematic Net Name
NC
NC
NC
FMC1_HPC_HA02_P
FMC1_HPC_HA02_N
FMC1_HPC_HA06_P
FMC1_HPC_HA06_N
FMC1_HPC_HA10_P
FMC1_HPC_HA10_N
FMC1_HPC_HA17_CC_P
FMC1_HPC_HA17_CC_N
FMC1_HPC_HA21_P
FMC1_HPC_HA21_N
FMC1_HPC_HA23_P
FMC1_HPC_HA23_N
FMC1_HPC_HB00_CC_P
FMC1_HPC_HB00_CC_N
FMC1_HPC_HB06_CC_P
FMC1_HPC_HB06_CC_N
FMC1_HPC_HB10_P
FMC1_HPC_HB10_N
FMC1_HPC_HB14_P
FMC1_HPC_HB14_N
FMC1_HPC_HB17_CC_P
FMC1_HPC_HB17_CC_N
FMC1_VIO_B_M2C
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
U1 FPGA
Pin
E33
D33
G36
G37
H38
G38
C35
C36
D37
D38
A35
A36
J25
J26
K23
J23
M22
L22
J21
H21
M24
L24
BANK 36
VCCO
