Table 1-27: J35 VITA 57.1 FMC 1 HPC Connections (Cont'd)
J35
FMC 1 Schematic Net Name
HPC Pin
G2 FMC1_HPC_CLK1_M2C_P
G3 FMC1_HPC_CLK1_M2C_N
G6 FMC1_HPC_LA00_CC_P
G7 FMC1_HPC_LA00_CC_N
G9 FMC1_HPC_LA03_P
G10 FMC1_HPC_LA03_N
G12 FMC1_HPC_LA08_P
G13 FMC1_HPC_LA08_N
G15 FMC1_HPC_LA12_P
G16 FMC1_HPC_LA12_N
G18 FMC1_HPC_LA16_P
G19 FMC1_HPC_LA16_N
G21 FMC1_HPC_LA20_P
G22 FMC1_HPC_LA20_N
G24 FMC1_HPC_LA22_P
G25 FMC1_HPC_LA22_N
G27 FMC1_HPC_LA25_P
G28 FMC1_HPC_LA25_N
G30 FMC1_HPC_LA29_P
G31 FMC1_HPC_LA29_N
G33 FMC1_HPC_LA31_P
G34 FMC1_HPC_LA31_N
G36 FMC1_HPC_LA33_P
G37 FMC1_HPC_LA33_N
G39 VADJ
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
J35
U1 FPGA
FMC 1
Pin
HPC Pin
N30 H1
M31 H2
K39 H4
K40 H5
M42 H7
L42 H8
M37 H10
M38 H11
R40 H13
P40 H14
K37 H16
K38 H17
Y29 H19
Y30 H20
R28 H22
P28 H23
K29 H25
K30 H26
T29 H28
T30 H29
M28 H31
M29 H32
U31 H34
T31 H35
H37
H38
H40
