Chapter 1: VC707 Evaluation Board Features
Table 1-12: PCIe Edge Connector Connections GTX Quad 115 (Cont'd)
FPGA (U1)
Net Name
Pin
PCIE_RX3_N AC5
PCIE_RX4_P AD4
PCIE_RX4_N AD3
PCIE_RX5_P AE6
PCIE_RX5_N AE5
PCIE_RX6_P AF4
PCIE_RX6_N AF3
PCIE_RX7_P AG6
PCIE_RX7_N AG5
PCIE_TX0_P W2
PCIE_TX0_N W1
PCIE_TX1_P AA2
PCIE_TX1_N AA1
PCIE_TX2_P AC2
PCIE_TX2_N AC1
PCIE_TX3_P AE2
PCIE_TX3_N AE1
PCIE_TX4_P AG2
PCIE_TX4_N AG1
PCIE_TX5_P AH4
PCIE_TX5_N AH3
PCIE_TX6_P AJ2
PCIE_TX6_N AJ1
PCIE_TX7_P AK4
PCIE_TX7_N AK3
Si5324_OUT_C_P AD8
Si5324_OUT_C_N AD7
PCIE_PRSNT_B J49 2, 4, 6
PCIE_WAKE_B AV33
PCIE_PERST_B AV35
36
Send Feedback
PCIe Edge Connector (P1)
Pin Name
B28 PETn3 Integrated Endpoint block receive pair
B33 PETp4 Integrated Endpoint block receive pair
B34 PETn4 Integrated Endpoint block receive pair
B37 PETp5 Integrated Endpoint block receive pair
B38 PETn5 Integrated Endpoint block receive pair
B41 PETp6 Integrated Endpoint block receive pair
B42 PETn6 Integrated Endpoint block receive pair
B45 PETp7 Integrated Endpoint block receive pair
B46 PETn7 Integrated Endpoint block receive pair
A16 PERp0 Integrated Endpoint block transmit pair
A17 PERn0 Integrated Endpoint block transmit pair
A21 PERp1 Integrated Endpoint block transmit pair
A22 PERn1 Integrated Endpoint block transmit pair
A25 PERp2 Integrated Endpoint block transmit pair
A26 PERn2 Integrated Endpoint block transmit pair
A29 PERp3 Integrated Endpoint block transmit pair
A30 PERn3 Integrated Endpoint block transmit pair
A35 PERp4 Integrated Endpoint block transmit pair
A36 PERn4 Integrated Endpoint block transmit pair
A39 PERp5 Integrated Endpoint block transmit pair
A40 PERn5 Integrated Endpoint block transmit pair
A43 PERp6 Integrated Endpoint block transmit pair
A44 PERn6 Integrated Endpoint block transmit pair
A47 PERp7 Integrated Endpoint block transmit pair
A48 PERn7 Integrated Endpoint block transmit pair
A13 REFCLK+ Integrated Endpoint block differential clock
pair from PCIe
A14 REFCLK- Integrated Endpoint block differential clock
pair from PCIe
A1 PRSNT#1 J49 Lane Size Select jumper
B11 WAKE# Integrated Endpoint block wake signal, not
connected on KC705 Board
A11 PERST Integrated Endpoint block reset signal
www.xilinx.com
Function
GTXE2_CHANNEL_X1Y8
GTXE2_CHANNEL_X1Y7
GTXE2_CHANNEL_X1Y7
GTXE2_CHANNEL_X1Y6
GTXE2_CHANNEL_X1Y6
GTXE2_CHANNEL_X1Y5
GTXE2_CHANNEL_X1Y5
GTXE2_CHANNEL_X1Y4
GTXE2_CHANNEL_X1Y4
GTXE2_CHANNEL_X1Y11
GTXE2_CHANNEL_X1Y11
GTXE2_CHANNEL_X1Y10
GTXE2_CHANNEL_X1Y10
GTXE2_CHANNEL_X1Y9
GTXE2_CHANNEL_X1Y9
GTXE2_CHANNEL_X1Y8
GTXE2_CHANNEL_X1Y8
GTXE2_CHANNEL_X1Y7
GTXE2_CHANNEL_X1Y7
GTXE2_CHANNEL_X1Y6
GTXE2_CHANNEL_X1Y6
GTXE2_CHANNEL_X1Y5
GTXE2_CHANNEL_X1Y5
GTXE2_CHANNEL_X1Y4
GTXE2_CHANNEL_X1Y4
MGT_BANK_114
(not Quad 115)
MGT_BANK_114
(not Quad 115)
NA
NA
NA
