Xilinx VC707 User Manual page 51

User LEDs
Figure 1-23
X-Ref Target - Figure 1-23
GPIO_LED_0
GPIO_LED_1
GPIO_LED_2
GPIO_LED_3
GPIO_LED_4
GPIO_LED_5
GPIO_LED_6
GPIO_LED_7
CPU Reset Pushbutton
Figure 1-24
X-Ref Target - Figure 1-24
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
shows the user LED circuits.
DS9 DS8 DS7
R154 R153 R152
49.9Ω 49.9Ω 49.9Ω
1% 1% 1%
GND
Figure 1-23: User LEDs
shows the CPU reset pushbutton switch circuit.
CPU_RESET
Figure 1-24: CPU Reset Pushbutton
www.xilinx.com
DS6 DS5 DS4
R151 R150 R149
49.9Ω 49.9Ω 49.9Ω
1% 1% 1%
SW8
4
3
R41
4.7kΩ
0.1W
5%
GND
Feature Descriptions
DS3 DS2
R148 R147
49.9Ω 49.9Ω
1% 1%
UG855_c1_23_020612
V 1V8
CC
1
2
UG885_c1_123_012513
51
