The connections between the USB mini-B connector at J2 and the PHY at U8 are listed in
Table
Table 1-6: USB Connector Pin Assignments and Signal Definitions Between J2 and U8
USB Connector
J2
Pin Name
1 VBUS USB_SMSC_VBUS
2 D_N USB_SMSC_HEADER_N
3 D_P USB_SMSC_HEADER_P
4 GND USB_SMC_GND
The connections between the USB 2.0 PHY at U8 and the FPGA are listed in
Table 1-7: USB 2.0 ULPI Transceiver Connections to the FPGA
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
1-6.
Net Name
+5V from host system
Bidirectional differential serial data (N-side)
Bidirectional differential serial data (P-side)
Signal ground
FPGA (U1) Pin Net Name
AV36 USB_SMSC_DATA0
AW36 USB_SMSC_DATA1
BA34 USB_SMSC_DATA2
BB34 USB_SMSC_DATA3
BA36 USB_SMSC_DATA4
AT34 USB_SMSC_DATA5
www.xilinx.com
Description
USB3320 (U8) Pin
3
4
5
6
7
9
Send Feedback
Feature Descriptions
USB3320 (U8)
Pin
22
19
18
33
Table 1-7.
