Table A-3: Default Jumper Settings (Cont'd)
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
Jumper
J43 XADC VCC Select Header
J44 USB Mini-B Connector J2 GND jumper
J45 USB SMBC U8 VBUS
J49 PCIe Bus Width Select Header
J50 TI Controller U64 Addr 54 Reset jumper
J51 FMC_VADJ_ON_B jumper
J52 FPGA U1 INIT_B-to-PROG_B jumper
J53 XADC VCC5V0-to-XADC_VCC5V0 jumper
J54 XADC REF3012 U35 V
www.xilinx.com
Default Jumper Settings
Function
Select
IN
Send Feedback
Default Jumper
Position
2–3
None
1–2
1-2
None
1–2
None
1–2
1–2
