set_property PACKAGE_PIN T8 [get_ports FMC2_HPC_GBTCLK1_M2C_C_P]
set_property PACKAGE_PIN T7 [get_ports FMC2_HPC_GBTCLK1_M2C_C_N]
set_property PACKAGE_PIN K8 [get_ports FMC2_HPC_GBTCLK0_M2C_C_P]
set_property PACKAGE_PIN K7 [get_ports FMC2_HPC_GBTCLK0_M2C_C_N]
#FMC1
set_property PACKAGE_PIN L39 [get_ports FMC1_HPC_CLK0_M2C_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_CLK0_M2C_P]
set_property PACKAGE_PIN L40 [get_ports FMC1_HPC_CLK0_M2C_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_CLK0_M2C_N]
set_property PACKAGE_PIN AN34 [get_ports FMC1_HPC_PG_M2C_LS]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_PG_M2C_LS]
set_property PACKAGE_PIN AM31 [get_ports FMC1_HPC_PRSNT_M2C_B_LS]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_PRSNT_M2C_B_LS]
set_property PACKAGE_PIN N30 [get_ports FMC1_HPC_CLK1_M2C_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_CLK1_M2C_P]
set_property PACKAGE_PIN M31 [get_ports FMC1_HPC_CLK1_M2C_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_CLK1_M2C_N]
set_property PACKAGE_PIN AL32 [get_ports FMC_C2M_PG_LS]
set_property IOSTANDARD LVCMOS18 [get_ports FMC_C2M_PG_LS]
set_property PACKAGE_PIN AH35 [get_ports FMC_VADJ_ON_B_LS]
set_property IOSTANDARD LVCMOS18 [get_ports FMC_VADJ_ON_B_LS]
set_property PACKAGE_PIN E2 [get_ports FMC1_HPC_DP0_C2M_P]
set_property PACKAGE_PIN D8 [get_ports FMC1_HPC_DP0_M2C_P]
set_property PACKAGE_PIN E1 [get_ports FMC1_HPC_DP0_C2M_N]
set_property PACKAGE_PIN D7 [get_ports FMC1_HPC_DP0_M2C_N]
set_property PACKAGE_PIN D4 [get_ports FMC1_HPC_DP1_C2M_P]
set_property PACKAGE_PIN C6 [get_ports FMC1_HPC_DP1_M2C_P]
set_property PACKAGE_PIN D3 [get_ports FMC1_HPC_DP1_C2M_N]
set_property PACKAGE_PIN C5 [get_ports FMC1_HPC_DP1_M2C_N]
set_property PACKAGE_PIN C2 [get_ports FMC1_HPC_DP2_C2M_P]
set_property PACKAGE_PIN B8 [get_ports FMC1_HPC_DP2_M2C_P]
set_property PACKAGE_PIN C1 [get_ports FMC1_HPC_DP2_C2M_N]
set_property PACKAGE_PIN B7 [get_ports FMC1_HPC_DP2_M2C_N]
set_property PACKAGE_PIN B4 [get_ports FMC1_HPC_DP3_C2M_P]
set_property PACKAGE_PIN A6 [get_ports FMC1_HPC_DP3_M2C_P]
set_property PACKAGE_PIN B3 [get_ports FMC1_HPC_DP3_C2M_N]
set_property PACKAGE_PIN A5 [get_ports FMC1_HPC_DP3_M2C_N]
set_property PACKAGE_PIN J2 [get_ports FMC1_HPC_DP4_C2M_P]
set_property PACKAGE_PIN H8 [get_ports FMC1_HPC_DP4_M2C_P]
set_property PACKAGE_PIN J1 [get_ports FMC1_HPC_DP4_C2M_N]
set_property PACKAGE_PIN H7 [get_ports FMC1_HPC_DP4_M2C_N]
set_property PACKAGE_PIN H4 [get_ports FMC1_HPC_DP5_C2M_P]
set_property PACKAGE_PIN G6 [get_ports FMC1_HPC_DP5_M2C_P]
set_property PACKAGE_PIN H3 [get_ports FMC1_HPC_DP5_C2M_N]
set_property PACKAGE_PIN G5 [get_ports FMC1_HPC_DP5_M2C_N]
set_property PACKAGE_PIN G2 [get_ports FMC1_HPC_DP6_C2M_P]
set_property PACKAGE_PIN F8 [get_ports FMC1_HPC_DP6_M2C_P]
set_property PACKAGE_PIN G1 [get_ports FMC1_HPC_DP6_C2M_N]
set_property PACKAGE_PIN F7 [get_ports FMC1_HPC_DP6_M2C_N]
set_property PACKAGE_PIN F4 [get_ports FMC1_HPC_DP7_C2M_P]
set_property PACKAGE_PIN E6 [get_ports FMC1_HPC_DP7_M2C_P]
set_property PACKAGE_PIN F3 [get_ports FMC1_HPC_DP7_C2M_N]
set_property PACKAGE_PIN E5 [get_ports FMC1_HPC_DP7_M2C_N]
#FMC1 LA
set_property PACKAGE_PIN K39 [get_ports FMC1_HPC_LA00_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_LA00_CC_P]
set_property PACKAGE_PIN K40 [get_ports FMC1_HPC_LA00_CC_N]
