Chapter 1: VC707 Evaluation Board Features
Table 1-21: FPGA to HDMI Codec Connections (ADV7511) (Cont'd)
FPGA (U1) Pin Schematic Net Name
Table 1-22
Table 1-22: ADV7511 to HDMI Connector Connections
Information about the ADV7511 is available on the Analog Devices website
Search for the term ADV7511KSTZ-P.
46
Send Feedback
AU21 HDMI_D31
AT21 HDMI_D32
AW22 HDMI_D33
AW23 HDMI_D34
AV23 HDMI_D35
AP21 HDMI_DE
AR23 HDMI_SPDIF
AU23 HDMI_CLK
AT22 HDMI_VSYNC
AU22 HDMI_HSYNC
AM24 HDMI_INT
AR22 HDMI_SPDIF_OUT
lists the connections between the codec and the HDMI connector P2.
ADV7511 (U48) Net Name
36 HDMI_D0_P
35 HDMI_D0_N
40 HDMI_D1_P
39 HDMI_D1_N
43 HDMI_D2_P
42 HDMI_D2_N
33 HDMI_CLK_P
32 HDMI_CLK_N
54 HDMI_DDCSDA
53 HDMI_DDCSCL
52 HDMI_HEAC_P
51 HDMI_HEAC_N
48 HDMI_CRC
www.xilinx.com
ADV7511 (U48)
Pin Number Pin Name
61 D31
60 D32
59 D33
58 D34
57 D35
97 DE
10 SPDIF
79 CLK
2 VSYNC
98 HSYNC
45 INT
46 SPDIF_OUT
HDMI Connector
P2 Pin
7
9
4
6
1
3
10
12
16
15
14
19
13
[Ref 22].
