set_property PACKAGE_PIN AN23 [get_ports HDMI_R_D15]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D15]
set_property PACKAGE_PIN AM23 [get_ports HDMI_R_D16]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D16]
set_property PACKAGE_PIN AN24 [get_ports HDMI_R_D17]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D17]
set_property PACKAGE_PIN AY24 [get_ports HDMI_R_D18]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D18]
set_property PACKAGE_PIN BB22 [get_ports HDMI_R_D19]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D19]
set_property PACKAGE_PIN BA22 [get_ports HDMI_R_D20]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D20]
set_property PACKAGE_PIN BA25 [get_ports HDMI_R_D21]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D21]
set_property PACKAGE_PIN AY25 [get_ports HDMI_R_D22]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D22]
set_property PACKAGE_PIN AY22 [get_ports HDMI_R_D23]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D23]
set_property PACKAGE_PIN AY23 [get_ports HDMI_R_D24]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D24]
set_property PACKAGE_PIN AV24 [get_ports HDMI_R_D25]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D25]
set_property PACKAGE_PIN AU24 [get_ports HDMI_R_D26]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D26]
set_property PACKAGE_PIN AW21 [get_ports HDMI_R_D27]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D27]
set_property PACKAGE_PIN AV21 [get_ports HDMI_R_D28]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D28]
set_property PACKAGE_PIN AT24 [get_ports HDMI_R_D29]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D29]
set_property PACKAGE_PIN AR24 [get_ports HDMI_R_D30]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D30]
set_property PACKAGE_PIN AU21 [get_ports HDMI_R_D31]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D31]
set_property PACKAGE_PIN AT21 [get_ports HDMI_R_D32]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D32]
set_property PACKAGE_PIN AW22 [get_ports HDMI_R_D33]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D33]
set_property PACKAGE_PIN AW23 [get_ports HDMI_R_D34]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D34]
set_property PACKAGE_PIN AV23 [get_ports HDMI_R_D35]
set_property IOSTANDARD LVCMOS18 [get_ports HDMI_R_D35]
#ETHERNET
set_property PACKAGE_PIN AJ33 [get_ports PHY_RESET_LS]
set_property IOSTANDARD LVCMOS18 [get_ports PHY_RESET_LS]
set_property PACKAGE_PIN AK33 [get_ports PHY_MDIO_LS]
set_property IOSTANDARD LVCMOS18 [get_ports PHY_MDIO_LS]
set_property PACKAGE_PIN AL31 [get_ports PHY_INT_LS]
set_property IOSTANDARD LVCMOS18 [get_ports PHY_INT_LS]
set_property PACKAGE_PIN AH31 [get_ports PHY_MDC_LS]
set_property IOSTANDARD LVCMOS18 [get_ports PHY_MDC_LS]
set_property PACKAGE_PIN AH8 [get_ports SGMIICLK_Q0_P]
set_property PACKAGE_PIN AH7 [get_ports SGMIICLK_Q0_N]
set_property PACKAGE_PIN AN2 [get_ports SGMII_TX_P]
set_property PACKAGE_PIN AM8 [get_ports SGMII_RX_P]
set_property PACKAGE_PIN AN1 [get_ports SGMII_TX_N]
set_property PACKAGE_PIN AM7 [get_ports SGMII_RX_N]
