Xilinx VC707 User Manual page 73

Table 1-30
UCD9248 PMBus controller at address 52 (U42).
Table 1-30: Power Rail Specifications for UCD9248 PMBus Controller at Address 52
Rail Rail Schematic
Number Name Rail Name
1 Rail #1 VCCINT_FPGA
2 Rail #2 VCCAUX
3 Rail #3 VCC3V3
4 Rail #4 VADJ
Notes:
1. The values defined in these columns are the voltage, current, and temperature thresholds that cause the regulator to shut down if
the value is exceeded.
Table 1-31
UCD9248 PMBus controller at address 53 (U43).
Table 1-31: Power Rail Specifications for UCD9248 PMBus Controller at Address 53
Rail Rail Schematic
Number Name Rail Name
1 Rail #1 VCC2V5_FPGA
2 Rail #2 VCC1V5
3 Rail #3 MGTAVCC
4 Rail #4 MGTAVTT
Notes:
1. The values defined in these columns are the voltage, current, and temperature thresholds that causes the regulator to shut down if
the value is exceeded.
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
defines the voltage and current values for each power rail controlled by the
1 0.9 0.85 0
1.8 1.62 1.53 0
3.3 2.97 2.805 0
1.8 1.62 1.53 0
defines the voltage and current values for each power rail controlled by the
2.5 2.25 2.125 0
1.5 1.35 1.275 0
1 0.9 0.85 0
1.2 1.08 1.02 0
www.xilinx.com
Feature Descriptions
Shutdown Threshold
5 10 1 1.15
5 5 1 2.07
5 4 1 3.795
5 3 1 2.07
Shutdown Threshold
5 1 1 2.875
5 0 1 1.725
5 7 1 1.45
5 8 1 1.38
Send Feedback
(1)
20 90
10.41 90
10.41 90
10.41 90
(1)
10.41 90
10.41 90
10.41 90
10.41 90
73
