Table 1-28: J37 VITA 57.1 FMC 2 HPC Connections (Cont'd)
J37 FMC 2
Schematic Net Name
HPC Pin
E22 FMC2_HPC_HB03_N
E24 FMC2_HPC_HB05_P
E25 FMC2_HPC_HB05_N
E27 FMC2_HPC_HB09_P
E28 FMC2_HPC_HB09_N
E30 FMC2_HPC_HB13_P
E31 FMC2_HPC_HB13_N
E33 FMC2_HPC_HB19_P
E34 FMC2_HPC_HB19_N
E36 FMC2_HPC_HB21_P
E37 FMC2_HPC_HB21_N
E39 VADJ
G2 FMC2_HPC_CLK1_M2C_P
G3 FMC2_HPC_CLK1_M2C_N
G6 FMC2_HPC_LA00_CC_P
G7 FMC2_HPC_LA00_CC_N
G9 FMC2_HPC_LA03_P
G10 FMC2_HPC_LA03_N
G12 FMC2_HPC_LA08_P
G13 FMC2_HPC_LA08_N
G15 FMC2_HPC_LA12_P
G16 FMC2_HPC_LA12_N
G18 FMC2_HPC_LA16_P
G19 FMC2_HPC_LA16_N
G21 FMC2_HPC_LA20_P
G22 FMC2_HPC_LA20_N
G24 FMC2_HPC_LA22_P
G25 FMC2_HPC_LA22_N
G27 FMC2_HPC_LA25_P
G28 FMC2_HPC_LA25_N
G30 FMC2_HPC_LA29_P
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
U1 FPGA J37 FMC 2
Pin HPC Pin
AU16 F22 FMC2_HPC_HB02_P
BA17 F23 FMC2_HPC_HB02_N
BB17 F25 FMC2_HPC_HB04_P
AV20 F26 FMC2_HPC_HB04_N
AW20 F28 FMC2_HPC_HB08_P
AT20 F29 FMC2_HPC_HB08_N
AT19 F31 FMC2_HPC_HB12_P
AP18 F32 FMC2_HPC_HB12_N
AP17 F34 FMC2_HPC_HB16_P
AN19 F35 FMC2_HPC_HB16_N
AN18 F37 FMC2_HPC_HB20_P
F38 FMC2_HPC_HB20_N
F40 VADJ
U39 H1 NC
T39 H2 FMC2_HPC_PRSNT_M2C_B
AD40 H4 FMC2_HPC_CLK0_M2C_P
AD41 H5 FMC2_HPC_CLK0_M2C_N
AJ42 H7 FMC2_HPC_LA02_P
AK42 H8 FMC2_HPC_LA02_N
AD42 H10 FMC2_HPC_LA04_P
AE42 H11 FMC2_HPC_LA04_N
Y39 H13 FMC2_HPC_LA07_P
AA39 H14 FMC2_HPC_LA07_N
AJ40 H16 FMC2_HPC_LA11_P
AJ41 H17 FMC2_HPC_LA11_N
V33 H19 FMC2_HPC_LA15_P
V34 H20 FMC2_HPC_LA15_N
W32 H22 FMC2_HPC_LA19_P
W33 H23 FMC2_HPC_LA19_N
R33 H25 FMC2_HPC_LA21_P
R34 H26 FMC2_HPC_LA21_N
W36 H28 FMC2_HPC_LA24_P
www.xilinx.com
Feature Descriptions
Schematic Net Name
Send Feedback
U1 FPGA Pin
AV16
AW16
AU18
AV18
AY20
BA20
AV19
AT20
AR18
AR17
AK17
AL17
AG32
AF39
AF40
AK39
AL39
AL41
AL42
AC40
AC41
Y42
AA42
AC38
AC39
U32
U33
P35
P36
U34
