set_property PACKAGE_PIN G38 [get_ports FMC1_HPC_HA10_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA10_N]
set_property PACKAGE_PIN J37 [get_ports FMC1_HPC_HA11_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA11_P]
set_property PACKAGE_PIN J38 [get_ports FMC1_HPC_HA11_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA11_N]
set_property PACKAGE_PIN B37 [get_ports FMC1_HPC_HA12_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA12_P]
set_property PACKAGE_PIN B38 [get_ports FMC1_HPC_HA12_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA12_N]
set_property PACKAGE_PIN B36 [get_ports FMC1_HPC_HA13_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA13_P]
set_property PACKAGE_PIN A37 [get_ports FMC1_HPC_HA13_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA13_N]
set_property PACKAGE_PIN E37 [get_ports FMC1_HPC_HA14_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA14_P]
set_property PACKAGE_PIN E38 [get_ports FMC1_HPC_HA14_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA14_N]
set_property PACKAGE_PIN C33 [get_ports FMC1_HPC_HA15_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA15_P]
set_property PACKAGE_PIN C34 [get_ports FMC1_HPC_HA15_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA15_N]
set_property PACKAGE_PIN B39 [get_ports FMC1_HPC_HA16_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA16_P]
set_property PACKAGE_PIN A39 [get_ports FMC1_HPC_HA16_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA16_N]
set_property PACKAGE_PIN C35 [get_ports FMC1_HPC_HA17_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA17_CC_P]
set_property PACKAGE_PIN C36 [get_ports FMC1_HPC_HA17_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA17_CC_N]
set_property PACKAGE_PIN F39 [get_ports FMC1_HPC_HA18_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA18_P]
set_property PACKAGE_PIN E39 [get_ports FMC1_HPC_HA18_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA18_N]
set_property PACKAGE_PIN B32 [get_ports FMC1_HPC_HA19_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA19_P]
set_property PACKAGE_PIN B33 [get_ports FMC1_HPC_HA19_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA19_N]
set_property PACKAGE_PIN B34 [get_ports FMC1_HPC_HA20_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA20_P]
set_property PACKAGE_PIN A34 [get_ports FMC1_HPC_HA20_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA20_N]
set_property PACKAGE_PIN D37 [get_ports FMC1_HPC_HA21_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA21_P]
set_property PACKAGE_PIN D38 [get_ports FMC1_HPC_HA21_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA21_N]
set_property PACKAGE_PIN F36 [get_ports FMC1_HPC_HA22_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA22_P]
set_property PACKAGE_PIN F37 [get_ports FMC1_HPC_HA22_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA22_N]
set_property PACKAGE_PIN A35 [get_ports FMC1_HPC_HA23_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA23_P]
set_property PACKAGE_PIN A36 [get_ports FMC1_HPC_HA23_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HA23_N]
#FMC1 HB
set_property PACKAGE_PIN J25 [get_ports FMC1_HPC_HB00_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HPC_HB00_CC_P]
set_property PACKAGE_PIN J26 [get_ports FMC1_HPC_HB00_CC_N]
