Appendix A: Default Switch and Jumper Settings

Configuration DIP Switch SW11

See
Figure A-2
X-Ref Target - Figure A-2
The default mode setting M[2:0] = 010 selects Master BPI configuration at board
power-on.
Table A-2: SW11 Default Switch Settings

Default Jumper Settings

See
Table A-3: Default Jumper Settings
80
Send Feedback
Figure 1-2, page 10 Item 29 for location of SW11. Default settings are shown in
and details are listed in
ON Position = 1
Figure A-2: SW11 Default Settings
Position Function
1 FLASH_A25
2 FLASH_A24
3 FPGA_M2
4 FPGA_M1
5 FPGA_M0
Figure 1-2, page 10 for locations of jumpers listed in
Jumper
J6 SFP Enable
J9 XADC GND ferrite filter bypass jumper
J10 XADC GND-to-XADC_AGND jumper
J11 TI Controller U42 Addr 52 Reset jumper
J12 TI Controller U43 Addr 53 Reset jumper
J13 USB Mini-B Connector J2 VBUS
J14 USB SMBC U8 CLKOUT selector
J38 SFP RX Rate: 1-2 = Full BW Rate, 2-3 = Low BW Rate
J39 SFP TX Rate: 1-2 = Full BW Rate, 2-3 = Low BW Rate
J42 XADC external 1.2V or internal VREFP selector
www.xilinx.com
Table A-2.
1 2 3 4 5
OFF Position = 0
UG885_aB_02_020612
Default
A25 Off
A24 Off
M0 Off
M1 On
M3 Off
Table
Function
A-3.
Default Jumper
Position
None
None
1–2
None
None
None
None
1–2
1–2
1–2
