Table 1-28
Note:
XC7VX485T-2FFG1761C FPGA installed on the VC707. Refer to the Virtex-7 FPGA VC707
Evaluation Kit Master Answer Record in
Table 1-28: J37 VITA 57.1 FMC 2 HPC Connections
J37 FMC 2
Schematic Net Name
HPC Pin
A2 FMC2_HPC_DP1_M2C_P
A3 FMC2_HPC_DP1_M2C_N
A6 FMC2_HPC_DP2_M2C_P
A7 FMC2_HPC_DP2_M2C_N
A10 FMC2_HPC_DP3_M2C_P
A11 FMC2_HPC_DP3_M2C_N
A14 FMC2_HPC_DP4_M2C_P
A15 FMC2_HPC_DP4_M2C_N
A18 FMC2_HPC_DP5_M2C_P
A19 FMC2_HPC_DP5_M2C_N
A22 FMC2_HPC_DP1_C2M_P
A23 FMC2_HPC_DP1_C2M_N
A26 FMC2_HPC_DP2_C2M_P
A27 FMC2_HPC_DP2_C2M_N
A30 FMC2_HPC_DP3_C2M_P
A31 FMC2_HPC_DP3_C2M_N
A34 FMC2_HPC_DP4_C2M_P
A35 FMC2_HPC_DP4_C2M_N
A38 FMC2_HPC_DP5_C2M_P
A39 FMC2_HPC_DP5_C2M_N
C2 FMC2_HPC_DP0_C2M_P
C3 FMC2_HPC_DP0_C2M_N
C6 FMC2_HPC_DP0_M2C_P
C7 FMC2_HPC_DP0_M2C_N
C10 FMC2_HPC_LA06_P
C11 FMC2_HPC_LA06_N
C14 FMC2_HPC_LA10_P
C15 FMC2_HPC_LA10_N
VC707 Evaluation Board
UG885 (v1.4) May 12, 2014
lists the connections between the FMC2 HPC J37 connector and the FPGA U1.
The FMC2 HPC HB00-HB21 pair connections are not available with the
U1 FPGA J37 FMC 2
Pin HPC Pin
N6 B1
N5 B4
L6 B5
L5 B8
J6 B9
J5 B12
W6 B13
W5 B16
V4 B17
V3 B20
M4 B21
M3 B24
L2 B25
L1 B28
K4 B29
K3 B32
U2 B33
U1 B36
T4 B37
T3 B40
N2 D1
N1 D4
P8 D5
P7 D8
AD38 D9
AE38 D11
AB41 D12
AB42 D14
www.xilinx.com
Appendix F: References for more information.
Schematic Net Name
NC
NC
NC
NC
NC
FMC2_HPC_DP7_M2C_P
FMC2_HPC_DP7_M2C_N
FMC2_HPC_DP6_M2C_P
FMC2_HPC_DP6_M2C_N
FMC2_HPC_GBTCLK1_M2C_P
FMC2_HPC_GBTCLK1_M2C_N
NC
NC
NC
NC
FMC2_HPC_DP7_C2M_P
FMC2_HPC_DP7_C2M_N
FMC2_HPC_DP6_C2M_P
FMC2_HPC_DP6_C2M_N
NC
PWRCTL1_VCC4B_PG
FMC2_HPC_GBTCLK0_M2C_P
FMC2_HPC_GBTCLK0_M2C_N
FMC2_HPC_LA01_CC_P
FMC2_HPC_LA01_CC_N
FMC2_HPC_LA05_P
FMC2_HPC_LA05_N
FMC2_HPC_LA09_P
Feature Descriptions
U1 FPGA Pin
P4
P3
U6
U5
T8
T7
R6
R5
R2
R1
AL32
K8
K7
AF41
AG41
AF42
AG42
AJ38
