Xilinx VC707 User Manual page 68

Chapter 1: VC707 Evaluation Board Features
Table 1-28: J37 VITA 57.1 FMC 2 HPC Connections (Cont'd)
J37 FMC 2
Schematic Net Name
HPC Pin
G31 FMC2_HPC_LA29_N
G33 FMC2_HPC_LA31_P
G34 FMC2_HPC_LA31_N
G36 FMC2_HPC_LA33_P
G37 FMC2_HPC_LA33_N
G39 VADJ
J2 NC
J3 NC
J6 FMC2_HPC_HA03_P
J7 FMC2_HPC_HA03_N
J9 FMC2_HPC_HA07_P
J10 FMC2_HPC_HA07_N
J12 FMC2_HPC_HA11_P
J13 FMC2_HPC_HA11_N
J15 FMC2_HPC_HA14_P
J16 FMC2_HPC_HA14_N
J18 FMC2_HPC_HA18_P
J19 FMC2_HPC_HA18_N
J21 FMC2_HPC_HA22_P
J22 FMC2_HPC_HA22_N
J24 FMC2_HPC_HB01_P
J25 FMC2_HPC_HB01_N
J27 FMC2_HPC_HB07_P
J28 FMC2_HPC_HB07_N
J30 FMC2_HPC_HB11_P
J31 FMC2_HPC_HB11_N
J33 FMC2_HPC_HB15_P
J34 FMC2_HPC_HB15_N
J36 FMC2_HPC_HB18_P
J37 FMC2_HPC_HB18_N
68
Send Feedback
U1 FPGA J37 FMC 2
Pin HPC Pin
W37 H29 FMC2_HPC_LA24_N
V39 H31 FMC2_HPC_LA28_P
V40 H32 FMC2_HPC_LA28_N
T36 H34 FMC2_HPC_LA30_P
R37 H35 FMC2_HPC_LA30_N
H37 FMC2_HPC_LA32_P
H38 FMC2_HPC_LA32_N
H40 VADJ
K1 NC
K4 NC
AA29 K5 NC
AA30 K7 FMC2_HPC_HA02_P
AC31 K8 FMC2_HPC_HA02_N
AD31 K10 FMC2_HPC_HA06_P
AE34 K11 FMC2_HPC_HA06_N
AE35 K13 FMC2_HPC_HA10_P
AF35 K14 FMC2_HPC_HA10_N
AF36 K16 FMC2_HPC_HA17_CC_P
AB36 K17 FMC2_HPC_HA17_CC_N
AB37 K19 FMC2_HPC_HA21_P
Y35 K20 FMC2_HPC_HA21_N
AA36 K22 FMC2_HPC_HA23_P
AM16 K23 FMC2_HPC_HA23_N
AN16 K25 FMC2_HPC_HB00_CC_P
BB19 K26 FMC2_HPC_HB00_CC_N
BB18 K28 FMC2_HPC_HB06_CC_P
AM18 K29 FMC2_HPC_HB06_CC_N
AM17 K31 FMC2_HPC_HB10_P
AL19 K32 FMC2_HPC_HB10_N
AM19 K34 FMC2_HPC_HB14_P
AJ18 K35 FMC2_HPC_HB14_N
AJ17 K37 FMC2_HPC_HB17_CC_P
