Chapter 5 FUNCTION SETTINGS AND OPERATIONS
5.22 Setting the Tool Movement Speed
This function allows you set the movement speed of the tool in raised status separately from the cutting/
plotting speed. A tool movement that is faster than the cutting/plotting speed enables a reduction in the
overall cutting/plotting time.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
OPTION1
SPEED
(3) Press the [F4] key (OPTION2) to display the menu shown below.
FORCE
MOVE SPD
SPEED
(4) Press the [F2] key (MOVE SPD) to display the menu shown below.
FORCE
TOOL MOVE SPEED
SPEED = AUTO
SPEED
Use the [
] or [
Setting range: AUTO, 10, 20, 30, 40 (cm/s) [Default value: AUTO]
AUTO
When AUTO is selected, the pen movement speed is set to match the current cutting/plotting speed.
(5) Press the [PAUSE] key to cancel PAUSE mode.
This setting is retained in the plotter's internal memory even while the plotter is turned off.
5-24
OFFSET
OPTION2
QUALITY
OFFSET
POSITION OPT
TEST
QUALITY
OFFSET
QUALITY
] key to change the numeric value, and then press the [ENTER] key to confirm your selection.
10
20
30
40
