Changing the LAN Duplex Mode
This command determines the LAN interface duplex mode.
config:#
network ethernet <ETH> duplexMode <mode>
Variables:
<ETH> is one of the options -- eth1 or eth2.
Option Description
eth1 ETH1 port
eth2 ETH2 port
<mode> is one of the modes: auto, half or full.
Option Description
auto The PRO3X selects the optimum transmission mode
through auto-negotiation.
half Half duplex:
Data is transmitted in one direction (to or from the
PRO3X) at a time.
full Full duplex:
Data is transmitted in both directions simultaneously.
