Setting the IPv4 Address
After selecting the static IP configuration mode, you can use this command to assign a permanent IP address to the PRO3X.
config:# network ipv4 interface <ETH> address <ip address>
Variables:
<ETH> is one of the network interfaces: ETH1/ETH2, WIRELESS, or BRIDGE. Note that you must choose/configure the bridge
interface if your PRO3X is set to the bridging mode.
Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters of ETH1/ETH2
and WIRELESS interfaces do NOT function.
Interface Description
eth1 Determine the IPv4 address of the ETH1 interface
(that is, wired networking).
eth2 Determine the IPv4 address of the ETH2 interface
(that is, wired networking).
wireless Determine the IPv4 address of the WIRELESS interface
(that is, wireless networking).
Determine the IPv4 address of the BRIDGE interface
bridge
(that is, the bridging mode).
<ip address> is the IP address being assigned to your PRO3X. Its format is "IP address/prefix". For example, 192.168.84.99/24.
