<sensor type> is one of the following sensor types:
Sensor type
current
voltage
activePower
apparentPower
powerFactor
activeEnergy
Displayed information:
Without the parameter details only the reading, state, threshold, de-assertion hysteresis and assertion timeout settings of
the specified inlet pole sensor are displayed.
With the parameter details more sensor information is displayed, including resolution and range.
If the requested sensor type is not supported, the "Sensor is not available" message is displayed.
Additional sensors supported by specific models:
Specific PRO3X models support some or all of the following sensors. The CLI command(s) listed above can be also applied to
the following sensors. Note that the measurement unit of current values in CLI is A, not mA.
Sensor type
peakCurrent
reactivePower
displacementPowerFact
or
residualCurrent
residualDCCurrent
Description
Current sensor
Voltage sensor
Active power sensor
Apparent power sensor
Power factor sensor
Active energy sensor
Description
Peak current sensor
Reactive power sensor
Displacement power factor sensor
RCM current sensor
▪ For Type A, it is the sensor that detects
residual AC current.
▪ For Type B, it is the sensor that detects
both residual AC and DC current.
RCM DC current sensor - detects residual DC
current only.
Available only on PDUs with RCM Type B.
