Tracing the Route

This command syntax traces the network route between your PRO3X and a network host.
diag> traceroute <host> <useICMP>
Variables:
<host> is the name or IP address of the host you want to trace.
<useICMP> is optional. It has only one value -- useICMP. Type useICMP in the end of this command only when you want to
use ICMP packets rather than UDP packets.

Example - Ping Command

The following command checks the network connectivity of the host 192.168.84.222 by sending the ICMP ECHO_REQUEST
message to the host for 5 times.
diag> ping 192.168.84.222 count 5

Retrieving Previous Commands

If you would like to retrieve any command that was previously typed in the same connection session, press the Up arrow ( )
on the keyboard several times until the desired command is displayed.

Automatically Completing a Command

A CLI command always consists of several words. You can easily enter a command by typing first word(s) or letter(s) and then
pressing Tab or Ctrl+i instead of typing the whole command word by word.
To have a command completed automatically:
4. Type initial letters or words of the desired command. Make sure the letters or words you typed are unique so that
the CLI can identify the command you want.
5. Press Tab or Ctrl+i until the complete command appears.
6. If there are more than one possible commands, a list of these commands is displayed. Then type the full command.
Examples:
Example 1 (only one possible command):
Type the first word and the first letter of the second word of the "reset factorydefaults" command --
a.
that is, reset f.
b. Then press Tab or Ctrl+i to complete the second word.
PRO3X User Guide – Command Line Interface (CLI)
170 of 182
Using the PRO3X Command Line Interface (CLI)
