Changing The Outlet Name; Example - Outlet Naming - LEGRAND Server Technology PRO3X User Manual

Example 4 - Adding an IPv4 Role-based Access Control Rule
The following command creates a newIPv4 role-based access control rule and specifies its location in the list.
security roleBasedAccessControl ipv4 rule add 192.168.78.50 192.168.90.100 admin deny
insertAbove 3
Results:
A new IPv4 role-based access control rule is added, dropping all packets from any IPv4 address between 192.168.78.50 and
192.168.90.100 when the user is a member of the role "admin."
The newly-added IPv4 rule is inserted above the 3rd rule. That is, the new rule becomes the 3rd rule, and the original 3rd rule
becomes the 4th rule.
Outlet Configuration Commands
An outlet configuration command begins with outlet. Such a command allows you to configure an individual outlet.

Changing the Outlet Name

This command names an outlet.
config:# outlet <n> name "<name>"
Variables:
<n> is the number of the outlet that you want to configure.
<name> is a string comprising up to 64 ASCII printable characters. The <name> variable must be enclosed in quotes when it
contains spaces.

Example - Outlet Naming

The following command assigns the name "Win XP" to outlet 8.
config:# outlet 8 name "Win XP"
PRO3X User Guide – Command Line Interface (CLI)
104 of 182
Using the PRO3X Command Line Interface (CLI)
