Radius Settings - LEGRAND Server Technology PRO3X User Manual

bindDN <bind_DN>
bindPassword
sortPosition <position>
Examples:
Change the IP address of the 1st LDAP server
authentication ldap modify 1 host 192.168.3.3
Change both the IP address and TCP port of the 1st LDAP server
authentication ldap modify 1 host 192.168.3.3 port 633
Change the IP address, TCP port and the type of the L1st DAP server
authentication ldap modify 1 host 192.168.3.3 port 633 serverType activeDirectory
Removing an Existing LDAP Server
This command removes an existing LDAP server from the server list.
config:# authentication ldap delete <server_num>
Variables:
<server_num> is the sequential number of the specified server in the LDAP server list.

Radius Settings

All Radius-related commands begin with authentication radius.
If you enable Radius authentication, you must add at least one Radius server. Later you can modify or delete any existing
Radius server as needed.
Change the bind DN.
▪ <bind_DN> is the new bind DN.
Change the bind DN password.
d. First add the "bindPassword" parameter to the command, and press Enter.
e. The system prompts you for the input of the password.
f. Type the password and press Enter.
Change the priority of the server (that is, resorting).
▪ <position> is the new sequential number of the server in the LDAP server
list.
PRO3X User Guide – Command Line Interface (CLI)
129 of 182
Using the PRO3X Command Line Interface (CLI)
