<port> is the current SSH/SCP port number, or the port number of a specific link device in the Port-Forwarding chain.
▪
<filename> is the new filename of the downloaded file.
2. Type the password when prompted.
3. The system downloads the specified data from the PRO3X onto your computer.
▪
If you do NOT specify a new filename in the command, such as Scenarios 1 or 2, the downloaded file's default name
is "raw_config.txt."
▪
If you specify a new filename in the command, such as Scenarios 3 or 4, the downloaded file is renamed accordingly.
To upload raw configuration data:
4. Type one of the following SCP commands and press Enter.
Scenario 1: Only one PRO3X to configure, with the default SCP port
▪ SSH/SCP port is the default (22), and the accessed PRO3X is a standalone device.
▪ There is only one device to configure so a CSV file for device-specific settings is NOT needed.
scp <config file> <user name>@<device ip>:/raw_config_update
Scenario 2: Only one PRO3X to configure, with a non-default SCP port
▪ SSH/SCP port is NOT the default (22), or the accessed PRO3X is a Port-Forwarding link device.
▪ There is only one device to configure so a CSV file for device-specific settings is NOT needed.
scp -P <port> <config file> <user name>@<device ip>:/raw_config_update
Scenario 3: Multiple PRO3X to configure, with the default SCP port
▪ SSH/SCP port is the default (22), and the accessed PRO3X is a standalone device.
▪ There are multiple devices to configure so a CSV file for device-specific settings is needed during the
upload.
scp <dev_list file> <config file> <user name>@<device
ip>:/raw_config_update /match=<col>
Scenario 4: Multiple PRO3X to configure, with a non-default SCP port
▪ SSH/SCP port is NOT the default (22), or the accessed PRO3X is a Port-Forwarding link device.
▪ There are multiple devices to configure so a CSV file for device-specific settings is needed during the
upload.
scp -P <port> <dev_list file> <config file> <user name>@<device
ip>:/raw_config_update /match=<dev_col>
▪
<config file> is the filename of the custom raw configuration that you want to upload.
▪
<user name> is the "admin" or any user profile with Administrator Privileges.
▪
<device ip> is the IP address or hostname of the PRO3X where you want to upload the specified file.
▪
<port> is the current SSH/SCP port number, or the port number of a specific link device in the Port-Forwarding chain.
▪
<dev_list file> is the name of the CSV file for configuring multiple PRO3X with device-specific settings. For
device-specific settings in the <config file>, refer each device-specific configuration key to a specific column in
the <dev_list file>.
