Actuator Configuration Commands
An actuator configuration command begins with actuator. You can configure the name and location parameters of an
individual actuator.
You can configure various parameters for one actuator at a time.
Change the name:
config:# actuator <n> name "<name>"
Set the X coordinate:
config:# actuator <n> xlabel "<coordinate>"
Set the Y coordinate:
config:# actuator <n> ylabel "<coordinate>"
Set the Z coordinate:
config:# actuator <n> zlabel "<z_label>"
Modify the actuator's description:
config:# actuator <n> description "<description>"
Variables:
<n> is the ID number assigned to the actuator. The ID number can be found using the PRO3X web interface or CLI. It is an
integer starting at 1.
<name> is a string comprising up to 64 ASCII printable characters. The <name> variable must be enclosed in quotes when it
contains spaces.
<coordinate> is a string comprising up to 24 ASCII printable characters, and it must be enclosed in quotes.
There are two types of values for the <z_label> variable, depending on the Z coordinate format you set:
Type Description
Free form <coordinate> is a string comprising up to 24 ASCII
printable characters, and it must be enclosed in
quotes.
Rack units <coordinate> is an integer number in rack units.
<description> is a string comprising up to 64 ASCII printable characters, and it must be enclosed in quotes when it contains
spaces.
